Sanjivini Steel Center is one of the leading manufacturers, suppliers, and exporters of stainless steel 420 round bar in India. The Stainless Steel 420 Round Bar is made of martensitic stainless steel, which has a high yield strength of up to 1365 MPa at 316 degrees Celsius and a minimum tensile strength of 1620 MPa at 427 degrees Celsius. The standard values for yield and tensile strength are 495 MPa and 700 MPa, respectively. Micro Metals is one of the leading manufacturers of SS 420 rod and bars in a range of diameters, forms, and sizes. The material is composed of silicon, carbon, manganese, sulfur, phosphorus, and 11.5% nickel and chromium. There are several types, finishes, and specifications available, such as ASTM A276 type 420 Bright Round bars.
Bright, shiny, or dark finishes are all possible. Sizes vary from 3 mm to 350 mm. The wire, ingot, hex, rectangular, round, square, forging, wire mesh, billet, and more forms. Because the material is corrosion-resistant, UNS S42000 AISI 420 Black Bar can be utilized in normal corrosive applications without polishing. The levels of wear and tear resistance of martensitic steel grades are extremely high. The ASTM A479 Stainless Steel 420 Hex Bar is custom cut to length sizes and has a length range of 1 to 6 meters. The sizes of the various bars vary. The hex bars have the same thickness as the Stainless Steel 420 Square Bar, measuring 18 mm to 57 mm.
The sizes of the 420 Stainless Steel Flat Bar type, bright bars, and round bars range from 4mm to 100mm. Bars come in two varieties: cold-drawn and hot-rolled. The bars are employed in a variety of engineering applications, including shipbuilding, construction, and bridge building. The most popular kind of bar in this grade is the SS 420 Cold Drawn Round Bar. For additional information on the many bar kinds, including the ASTM A276 SS 420 Threaded Bar and others, please get in touch with us.
Stainless Steel 420 Round Bars are widely used across various industries due to their versatility and excellent properties. Here are some common applications:
Round bars made with 420 stainless steel specifications. For a prompt quote, please use the contact button if any specifications are not listed here.
Material | Stainless Steel 420 |
Size Tolerances | h10 and h11 |
Chamfering | Available in 30°, 45°, & 60° through fully automatic, both-end chamfering machine |
Heat Treatment | Annealed, Solution Annealed |
Size range | 12 mm–46 mm (1/2 inch–1 1 ¾ inch) |
Flat Bar Size Range | Thickness: 2–100mm/Width: 10–500mm |
Crack Test | Magnetic Particle Inspection (MPI) |
Length | 2 meters to 7.5 meters ( 8 feet to 24 feet), or Custom Length as per Requirement |
Available Forms | Rod, Channel, Rectangle, Precision Ground, Blocks, Round, Threaded, Profiles, Rings, Round Rod, Triangle, Hollow, Half Round, Ingot, Square, Hex (A/F), Rectangle, Billet, Forging etc. |
Tolerance | H8, H10, H9, H11, H12, K10, H13K9, K12K11, or as per clients’ requirements |
Manufacturing Technique | Hot Rolled, Cold Drawn, Cold Rolled, Forged |
Surface Finish | Cold (bright) drawn, centerless ground, peeled, Rough Turned, smooth turned, hot rolled, hot rolled annealed, Grinding, Bright, slit-rolled edge, Polish, Centreless Ground & Black |
STANDARD | WERKSTOFF NR. | UNS | JIS | EN | BS |
SS 420 | 1.4021 | S42000 | SUS 420 J1 | FeMi35Cr20Cu4Mo2 | 420S29 |
Grade | C | Mn | Si | P | S | Cr |
SS 420 | 0.15 | 1.00 | 1.00 | 0.04 | 0.03 | 14.0 – 12.0 |
Tensile Strength (PSI) | Yield Strength (PSI) | Reduction of Area | Elongation in 2" | Brinell Hardness |
95,000 | 50,000 | 55 | 25 | 175 |
Type | SIZES (mm) | SIZES (Inches) | ISO Tolerance |
---|---|---|---|
Cold Drawn and Polish | 3.00 – 75.00 | 1/8″ – 3.00″ | h8-h9-h10-h11 |
Cold Drawn and Ground | 10.00 – 75.00 | 5/6″ – 2.50″ | h8-h9-h10-h11 |
Peeled and Polished | 40.00 – 150.00 | 1.50″ – 6.00″ | h11, h11-DIN 1013 |
Peeled and Ground | 20.00 – 50.00 | 3/4″ – 2.00″ | h9-h10-h11 |
Cut to size on request (tolerance +2/-0 mm). 420 Stainless Steel Bars Standard lengths of 2000 mm up to 6000 mm.
5.0 | 45.0 |
6.0 | 50.0 |
7.0 | 55.0 |
8.0 | 60.0 |
9.0 | 65.0 |
10.0 | 70.0 |
12.0 | 75.0 |
16.0 | 80.0 |
20.0 | 90.0 |
25.0 | 100.0 |
30.0 | 130.0 |
35.0 | 160.0 |
40.0 | 200.0 |
Mill Test Certificates, EN 10204 3.1, Chemical Reports, Mechanical Reports, PMI Test Reports, Visual Inspection Reports, Third Party Inspection Reports, NABL Approved Lab reports, Destructive Test Report, Non Destructive Test Reports
Packing In Wooden Boxes, Plastic Bags, Steel Strip Bundled, or as per Customers Requests
Sizes and Specifications other than above can be manufactured on request
